Organix F3 Wattage

Order	Milliamps	144L
1	700 mA	310W (29287-37332 Lumens)
2	800 mA	355W (33471-42666 Lumens)
3	900 mA	400W (37655-47999 Lumens)
4	1000 mA	445W (41836-53332 Lumens)

Generated by wpDataTables

Organix F3 Lumens

Order	Model	15°	15° Lm/W	30°	30° Lm/W	55°	55° Lm/W	85°	85° Lm/W	Watts
1	ORX-F3-144L-700-27K7	29,287	94	29,644	96	30,859	100	31,956	103	310
2	ORX-F3-144L-700-27K8	27,422	88	27,757	90	28,894	93	29,922	97	310
3	ORX-F3-144L-700-30K8	29,401	95	29,759	96	30,979	100	32,081	103	310
4	ORX-F3-144L-700-30K7	31,665	102	32,051	103	33,364	108	34,551	111	310
5	ORX-F3-144L-700-35K8	29,401	95	29,759	96	30,979	100	32,081	103	310
6	ORX-F3-144L-700-40K8	31,665	102	32,051	103	33,364	108	34,551	111	310
7	ORX-F3-144L-700-40K7	34,214	110	34,631	112	36,050	116	37,332	120	310
8	ORX-F3-144L-700-50K8	31,665	102	32,051	103	33,364	108	34,551	111	310
9	ORX-F3-144L-700-50K7	34,214	110	34,631	112	36,050	116	37,332	120	310
10	ORX-F3-144L-800-27K7	33,471	94	33,879	95	35,267	99	36,522	103	355
11	ORX-F3-144L-800-27K8	31,340	88	31,722	89	33,022	93	34,196	96	355
12	ORX-F3-144L-800-30K8	33,601	95	34,011	96	35,404	100	36,664	103	355
13	ORX-F3-144L-800-30K7	36,189	102	36,630	103	38,131	107	39,487	111	355
14	ORX-F3-144L-800-35K8	33,601	95	34,011	96	35,404	100	36,664	103	355
15	ORX-F3-144L-800-40K8	36,189	102	36,630	103	38,131	107	39,487	111	355
16	ORX-F3-144L-800-40K7	39,102	110	39,578	111	41,200	116	42,666	120	355
17	ORX-F3-144L-800-50K8	36,189	102	36,630	103	38,131	107	39,487	111	355
18	ORX-F3-144L-800-50K7	39,102	110	39,578	111	41,200	116	42,666	120	355
19	ORX-F3-144L-900-27K7	37,655	94	38,114	95	39,675	99	41,087	103	400
20	ORX-F3-144L-900-27K8	35,257	88	35,687	89	37,149	93	38,471	96	400
21	ORX-F3-144L-900-30K8	37,801	95	38,262	96	39,830	100	41,247	103	400
22	ORX-F3-144L-900-30K7	40,712	102	41,209	103	42,897	107	44,423	111	400
23	ORX-F3-144L-900-35K8	37,801	95	38,262	96	39,830	100	41,247	103	400
24	ORX-F3-144L-900-40K8	40,712	102	41,209	103	42,897	107	44,423	111	400
25	ORX-F3-144L-900-40K7	43,989	110	44,526	111	46,350	116	47,999	120	400
26	ORX-F3-144L-900-50K8	40,712	102	41,209	103	42,897	107	44,423	111	400
27	ORX-F3-144L-900-50K7	43,989	110	44,526	111	46,350	116	47,999	120	400
28	ORX-F3-144L-1A-27K7	41,838	94	42,349	95	44,084	99	45,652	103	445
29	ORX-F3-144L-1A-27K8	39,175	88	39,652	89	41,277	93	42,745	96	445
30	ORX-F3-144L-1A-30K8	42,001	94	42,513	96	44,255	99	45,830	103	445
31	ORX-F3-144L-1A-30K7	45,236	102	45,787	103	47,663	107	49,359	111	445
32	ORX-F3-144L-1A-35K8	42,001	94	42,513	96	44,255	99	45,830	103	445
33	ORX-F3-144L-1A-40K8	45,236	102	45,787	103	47,663	107	49,359	111	445
34	ORX-F3-144L-1A-40K7	48,877	110	49,473	111	51,500	116	53,332	120	445
35	ORX-F3-144L-1A-50K8	45,236	102	45,787	103	47,663	107	49,359	111	445
36	ORX-F3-144L-1A-50K7	48,877	110	49,473	111	51,500	116	53,332	120	445

Generated by wpDataTables

Download WHY SILICONE OPTICS? Brochure to Learn more!

Form
• Elegant Die-Cast Aluminum Housing
• Corrosion Resistant Stainless Steel External Hardware
• Sleek, Low Profile Housing
• Spec Grade Performance
• Engineered For Optimum Thermal Management
• 9 Architectural Finishes Standard, RAL Colors Available

Function
• Micro Optics IES Distributions: T2, T3, T4, T5, 15°, 30°, 55° 85°
• 0-10V Dimming Drivers THD @ Max Load < 15% Power factor @ Max Load < 0.95
• Amber, 2700K, 3000K, 3500K, 4000K, or 5000K
• 4 Static LED Color Options
• 16L LED Configuration
• CRI 70, 80, or 90
• 5 Mils Powder Coat

Reliability
• Silicone Micro Optics
• 5 Year Standard Warranty
• IP67 Optics
