Organix F2 Wattage

Order	Milliamps	32L	64L
1	620 mA	60W (5711-7280 Lumens)	-
2	820 mA	80W (7305-9312 Lumens)	-
3	700 mA	-	139W (12397-15802 Lumens)
4	1000 mA	-	198W (18595-23703 Lumens)

Generated by wpDataTables

Organix F2 Lumens

Order	Model	15°	15° Lm/W	30°	30° Lm/W	55°	55° Lm/W	85°	85° Lm/W	Watts
1	ORX-F2-32L-620-27K7	5,711	95	5,781	96	6,018	100	6,232	104	60
2	ORX-F2-32L-620-27K8	5,348	89	5,412	90	5,635	94	5,835	97	60
3	ORX-F2-32L-620-30K8	5,733	96	5,803	97	6,041	101	6,256	104	60
4	ORX-F2-32L-620-30K7	6,175	103	6,250	104	6,506	108	6,738	112	60
5	ORX-F2-32L-620-35K8	5,733	96	5,803	97	6,041	101	6,256	104	60
6	ORX-F2-32L-620-40K8	6,175	103	6,250	104	6,506	108	6,738	112	60
7	ORX-F2-32L-620-40K7	6,672	111	6,753	113	7,030	117	7,280	121	60
8	ORX-F2-32L-620-50K8	6,175	103	6,250	104	6,506	108	6,738	112	60
9	ORX-F2-32L-620-50K7	6,672	111	6,753	113	7,030	117	7,280	121	60
10	ORX-F2-32L-820-27K7	7,305	91	7,394	92	7,697	96	7,971	100	80
11	ORX-F2-32L-820-27K8	6,840	85	6,923	87	7,207	90	7,464	93	80
12	ORX-F2-32L-820-30K8	7,333	92	7,423	93	7,727	97	8,002	100	80
13	ORX-F2-32L-820-30K7	7,898	99	7,994	100	8,322	104	8,618	108	80
14	ORX-F2-32L-820-35K8	7,333	92	7,423	93	7,727	97	8,002	100	80
15	ORX-F2-32L-820-40K8	7,898	99	7,994	100	8,322	104	8,618	108	80
16	ORX-F2-32L-820-40K7	8,534	107	8,638	108	8,992	112	9,312	116	80
17	ORX-F2-32L-820-50K8	7,898	99	7,994	100	8,322	104	8,618	108	80
18	ORX-F2-32L-820-50K7	8,534	107	8,638	108	8,992	112	9,312	116	80
19	ORX-F2-64L-700-27K7	12,397	89	12,548	90	13,062	94	13,526	97	139
20	ORX-F2-64L-700-27K8	11,607	84	11,749	85	12,230	88	12,665	91	139
21	ORX-F2-64L-700-30K8	12,445	90	12,597	91	13,113	94	13,579	98	139
22	ORX-F2-64L-700-30K7	13,403	96	13,567	98	14,123	102	14,625	105	139
23	ORX-F2-64L-700-35K8	12,445	90	12,597	91	13,113	94	13,579	98	139
24	ORX-F2-64L-700-40K8	13,403	96	13,567	98	14,123	102	14,625	105	139
25	ORX-F2-64L-700-40K7	14,482	104	14,659	105	15,259	110	15,802	114	139
26	ORX-F2-64L-700-50K8	13,403	96	13,567	98	14,123	102	14,625	105	139
27	ORX-F2-64L-700-50K7	14,482	104	14,659	105	15,259	110	15,802	114	139
28	ORX-F2-64L-1A-27K7	18,595	94	18,822	95	19,593	99	20,290	102	198
29	ORX-F2-64L-1A-27K8	17,411	88	17,623	89	18,345	93	18,998	96	198
30	ORX-F2-64L-1A-30K8	18,667	94	18,895	95	19,669	99	20,369	103	198
31	ORX-F2-64L-1A-30K7	20,105	102	20,350	103	21,184	107	21,937	111	198
32	ORX-F2-64L-1A-35K8	18,667	94	18,895	95	19,669	99	20,369	103	198
33	ORX-F2-64L-1A-40K8	20,105	102	20,350	103	21,184	107	21,937	111	198
34	ORX-F2-64L-1A-40K7	21,723	110	21,988	111	22,889	116	23,703	120	198
35	ORX-F2-64L-1A-50K8	20,105	102	20,350	103	21,184	107	21,937	111	198
36	ORX-F2-64L-1A-50K7	21,723	110	21,988	111	22,889	116	23,703	120	198

Generated by wpDataTables

Download WHY SILICONE OPTICS? Brochure to Learn more!

Form
• Elegant Die-Cast Aluminum Housing
• Corrosion Resistant Stainless Steel External Hardware
• Sleek, Low Profile Housing
• Spec Grade Performance
• Engineered For Optimum Thermal Management
• 9 Architectural Finishes Standard, RAL Colors Available

Function
• Micro Optics IES Distributions: T2, T3, T4, T5, 15°, 30°, 55° 85°
• 0-10V Dimming Drivers THD @ Max Load < 15% Power factor @ Max Load < 0.95
• Amber, 2700K, 3000K, 3500K, 4000K, or 5000K
• 4 Static LED Color Options
• CRI 70, 80, or 90
• 5 Mils Powder Coat

Reliability
• Silicone Micro Optics
• 5 Year Standard Warranty
• IP67 Optics
