Organix 1-CM BUG Ratings

Order	Model	T2 B.U.G.	T3 B.U.G.	T4 B.U.G.	T5 B.U.G.	Watts
1	ORX-1-CM-16L-425-27K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
2	ORX-1-CM-16L-425-27K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
3	ORX-1-CM-16L-425-30K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
4	ORX-1-CM-16L-425-30K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
5	ORX-1-CM-16L-425-35K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
6	ORX-1-CM-16L-425-40K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
7	ORX-1-CM-16L-425-40K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
8	ORX-1-CM-16L-425-50K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
9	ORX-1-CM-16L-425-50K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	22
10	ORX-1-CM-16L-530-27K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
11	ORX-1-CM-16L-530-27K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
12	ORX-1-CM-16L-530-30K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
13	ORX-1-CM-16L-530-30K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
14	ORX-1-CM-16L-530-35K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
15	ORX-1-CM-16L-530-40K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
16	ORX-1-CM-16L-530-40K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
17	ORX-1-CM-16L-530-50K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
18	ORX-1-CM-16L-530-50K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	28
19	ORX-1-CM-16L-700-27K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	37
20	ORX-1-CM-16L-700-27K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	37
21	ORX-1-CM-16L-700-30K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	37
22	ORX-1-CM-16L-700-30K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	37
23	ORX-1-CM-16L-700-35K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B2-U0-B1	37
24	ORX-1-CM-16L-700-40K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	37
25	ORX-1-CM-16L-700-40K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	37
26	ORX-1-CM-16L-700-50K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	37
27	ORX-1-CM-16L-700-50K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	37
28	ORX-1-CM-16L-850-27K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
29	ORX-1-CM-16L-850-27K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
30	ORX-1-CM-16L-850-30K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
31	ORX-1-CM-16L-850-30K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
32	ORX-1-CM-16L-850-35K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
33	ORX-1-CM-16L-850-40K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
34	ORX-1-CM-16L-850-40K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
35	ORX-1-CM-16L-850-50K8	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43
36	ORX-1-CM-16L-850-50K7	B1-U0-B1	B1-U0-B1	B1-U0-B1	B3-U0-B1	43

Generated by wpDataTables

Organix 1-CM T4FTW and T5W BUG Ratings

Order	Model	T4FTW B.U.G.	T5W B.U.G.	T5W CLEAR LENS B.U.G.	Watts
1	ORX-1-CM-16L-42-27K7	B1-U0-G1	B2-U0-G1	B1-U0-G1	22
2	ORX-1-CM-16L-42-30K7	B1-U0-G1	B2-U0-G1	B1-U0-G1	22
3	ORX-1-CM-16L-42-40K7	B1-U0-G1	B2-U0-G1	B1-U0-G1	22
4	ORX-1-CM-16L-42-50K7	B1-U0-G1	B2-U0-G1	B1-U0-G1	22
5	ORX-1-CM-16L-53-27K7	B1-U0-G1	B3-U0-G1	B1-U0-G1	28
6	ORX-1-CM-16L-53-30K7	B1-U0-G1	B3-U0-G1	B1-U0-G1	28
7	ORX-1-CM-16L-53-40K7	B1-U0-G1	B3-U0-G1	B1-U0-G1	28
8	ORX-1-CM-16L-53-50K7	B1-U0-G1	B3-U0-G1	B1-U0-G1	28
9	ORX-1-CM-16L-7-27K7	B1-U0-G1	B3-U0-G1	B1-U0-G1	37
10	ORX-1-CM-16L-7-30K7	B1-U0-G1	B3-U0-G2	B1-U0-G1	37
11	ORX-1-CM-16L-7-40K7	B1-U0-G2	B3-U0-G2	B1-U0-G1	37
12	ORX-1-CM-16L-7-50K7	B1-U0-G2	B3-U0-G2	B1-U0-G1	37
13	ORX-1-CM-16L-85-27K7	B1-U0-G2	B3-U0-G1	B1-U0-G1	42
14	ORX-1-CM-16L-85-30K7	B1-U0-G2	B3-U0-G1	B1-U0-G1	42
15	ORX-1-CM-16L-85-40K7	B1-U0-G2	B3-U0-G2	B1-U0-G1	42
16	ORX-1-CM-16L-85-50K7	B1-U0-G2	B3-U0-G2	B1-U0-G1	42

Generated by wpDataTables

ORGANIX 1-CM AMBER BUG RATINGS

Model	T2 B.U.G	T3 B.U.G	T4FTW B.U.G	T5W B.U.G	Watts
ORX-1-CM-16L-42-AMBER	B0-U0-G0	B0-U0-G0	B0-U0-G0	B1-U0-G1	18
ORX-1-CM-16L-53-AMBER	B0-U0-G0	B0-U0-G0	B0-U0-G0	B1-U0-G1	23

Generated by wpDataTables

Organix 1-CM Wattage

Order	Milliamps	16L
1	425 mA	22W (1955-2607 Lumens)
2	530 mA	28W (2438-3251 Lumens)
3	700 mA	37W (3220-4294 Lumens)
4	850 mA	43W (3910-5214 Lumens)

Generated by wpDataTables

Organix 1-CM Lumens

Order	Model	T2 Lumens	T2 Lm/W	T3 Lumens	T3 Lm/W	T4 Lumens	T4 Lm/W	T5 Lumens	T5 Lm/W	Watts
1	ORX-1-CM-16L-425-27K7	2,126	97	2,133	97	2,088	95	2,232	101	22
2	ORX-1-CM-16L-425-27K8	1,991	90	1,997	91	1,955	89	2,089	95	22
3	ORX-1-CM-16L-425-30K8	2,135	97	2,141	97	2,096	95	2,240	102	22
4	ORX-1-CM-16L-425-30K7	2,299	104	2,306	105	2,258	103	2,413	110	22
5	ORX-1-CM-16L-425-35K8	2,135	97	2,141	97	2,096	95	2,240	102	22
6	ORX-1-CM-16L-425-40K8	2,299	104	2,306	105	2,258	103	2,413	110	22
7	ORX-1-CM-16L-425-40K7	2,484	113	2,492	113	2,440	111	2,607	119	22
8	ORX-1-CM-16L-425-50K8	2,299	104	2,306	105	2,258	103	2,413	110	22
9	ORX-1-CM-16L-425-50K7	2,484	113	2,492	113	2,440	111	2,607	119	22
10	ORX-1-CM-16L-530-27K7	2,652	95	2,660	95	2,604	93	2,783	99	28
11	ORX-1-CM-16L-530-27K8	2,483	89	2,490	89	2,438	87	2,606	93	28
12	ORX-1-CM-16L-530-30K8	2,662	95	2,670	95	2,614	93	2,794	100	28
13	ORX-1-CM-16L-530-30K7	2,867	102	2,876	103	2,816	101	3,009	107	28
14	ORX-1-CM-16L-530-35K8	2,662	95	2,670	95	2,614	93	2,794	100	28
15	ORX-1-CM-16L-530-40K8	2,867	102	2,876	103	2,816	101	3,009	107	28
16	ORX-1-CM-16L-530-40K7	3,098	111	3,107	111	3,042	109	3,251	116	28
17	ORX-1-CM-16L-530-50K8	2,867	102	2,876	103	2,816	101	3,009	107	28
18	ORX-1-CM-16L-530-50K7	3,098	111	3,107	111	3,042	109	3,251	116	28
19	ORX-1-CM-16L-700-27K7	3,502	95	3,513	95	3,439	93	3,676	99	37
20	ORX-1-CM-16L-700-27K8	3,279	89	3,289	89	3,220	87	3,442	93	37
21	ORX-1-CM-16L-700-30K8	3,516	95	3,526	95	3,453	93	3,690	100	37
22	ORX-1-CM-16L-700-30K7	3,786	102	3,798	103	3,719	101	3,974	107	37
23	ORX-1-CM-16L-700-35K8	3,516	95	3,526	95	3,453	93	3,690	100	37
24	ORX-1-CM-16L-700-40K8	3,786	102	3,798	103	3,719	101	3,974	107	37
25	ORX-1-CM-16L-700-40K7	4,091	111	4,104	111	4,018	109	4,294	116	37
26	ORX-1-CM-16L-700-50K8	3,786	102	3,798	103	3,719	101	3,974	107	37
27	ORX-1-CM-16L-700-50K7	4,091	111	4,104	111	4,018	109	4,294	116	37
28	ORX-1-CM-16L-850-27K7	4,253	99	4,265	99	4,176	97	4,463	104	43
29	ORX-1-CM-16L-850-27K8	3,982	93	3,994	93	3,910	91	4,179	97	43
30	ORX-1-CM-16L-850-30K8	4,269	99	4,282	100	4,193	98	4,481	104	43
31	ORX-1-CM-16L-850-30K7	4,598	107	4,612	107	4,516	105	4,826	112	43
32	ORX-1-CM-16L-850-35K8	4,269	99	4,282	100	4,193	98	4,481	104	43
33	ORX-1-CM-16L-850-40K8	4,598	107	4,612	107	4,516	105	4,826	112	43
34	ORX-1-CM-16L-850-40K7	4,968	116	4,983	116	4,879	113	5,214	121	43
35	ORX-1-CM-16L-850-50K8	4,598	107	4,612	107	4,516	105	4,826	112	43
36	ORX-1-CM-16L-850-50K7	4,968	116	4,983	116	4,879	113	5,214	121	43

Generated by wpDataTables

Organix 1-CM T4FTW and T5W Lumens

NA	Model	T4FTW	T4FTW LM/W	T5W	T5W LM/W	T5W CLEAR LENS	T5W CLEAR LENS LM/W	WATTAGE
1	ORX-1-CM-16L-42-27K7	2,523	115	2,580	117	2,034	92	22
2	ORX-1-CM-16L-42-30K7	2,728	124	2,789	127	2,199	100	22
3	ORX-1-CM-16L-42-40K7	2,948	134	3,014	137	2,376	108	22
4	ORX-1-CM-16L-42-50K7	2,948	134	3,014	137	2,376	108	22
5	ORX-1-CM-16L-53-27K7	2,996	107	3,475	124	2,780	99	28
6	ORX-1-CM-16L-53-30K7	3,239	116	3,758	134	3,006	107	28
7	ORX-1-CM-16L-53-40K7	3,500	125	4,060	145	3,248	116	28
8	ORX-1-CM-16L-53-50K7	3,500	125	4,060	145	3,248	116	28
9	ORX-1-CM-16L-7-27K7	3,674	99	4,529	122	3,611	98	37
10	ORX-1-CM-16L-7-30K7	3,972	107	4,897	132	3,904	106	37
11	ORX-1-CM-16L-7-40K7	4,292	116	5,291	143	4,218	114	37
12	ORX-1-CM-16L-7-50K7	4,292	116	5,291	143	4,218	114	37
13	ORX-1-CM-16L-85-27K7	4,085	97	4,587	109	3,664	87	42
14	ORX-1-CM-16L-85-30K7	4,416	105	4,960	118	3,961	94	42
15	ORX-1-CM-16L-85-40K7	4,772	114	5,359	128	4,280	102	42
16	ORX-1-CM-16L-85-50K7	4,772	114	5,359	128	4,280	102	42

Generated by wpDataTables

LUMEN CHART AMBER WITH T2

PART NUMBER	T2	LM/W	WATTAGE	BUG
ORX-1-CM-16L-42-AMBER	1,046.00	58.00	18	B0-U0-G0
ORX-1-CM-16L-53-AMBER	1,253.00	54.00	13	B0-U0-G0

Generated by wpDataTables

LUMEN CHART AMBER WITH T3

PART NUMBER	T3	LM/W	WATTAGE	BUG
ORX-1-CM-16L-42-AMBER	1,049.00	58.00	18	B0-U0-G0
ORX-1-CM-16L-53-AMBER	1,256.00	55.00	13	B0-U0-G0

Generated by wpDataTables

LUMEN CHART AMBER WITH T4FTW

PART NUMBER	T4FTW	LM/W	WATTAGE	BUG
ORX-1-CM-16L-42-AMBER	929.00	52.00	18	B0-U0-G1
ORX-1-CM-16L-53-AMBER	1,087.00	47.00	23	B0-U0-G1

Generated by wpDataTables

LUMEN CHART AMBER WITH T5W

PART NUMBER	T2	LM/W	WATTAGE	BUG
ORX-1-CM-16L-42-AMBER	1,269	71.00	18	B1-U0-G1
ORX-1-CM-16L-53-AMBER	1,641	71.00	23	B1-U0-G1

Generated by wpDataTables

Download WHY SILICONE OPTICS? Brochure to Learn more!

Form
• Elegant Die-Cast Aluminum Housing
• Corrosion Resistant Stainless Steel External Hardware
• Sleek, Low Profile Housing
• Spec Grade Performance
• Engineered For Optimum Thermal Management
• 9 Architectural Finishes Standard, RAL Colors Available

Function
• Micro Optics IES Distributions T2, T3, T4, T5
• 0-10V Dimming Drivers THD @ Max Load < 15% Power factor @ Max Load < 0.95
• Amber, 2700K, 3000K, 3500K, 4000K, or 5000K
• 16L LED Configuration
• CRI 70, 80, or 90
• 5 Mils Powder Coat

Reliability
• Silicone Micro Optics
• 5 Year Standard Warranty
• IP67 Optics
