| Order | Model | T2 B.U.G. | T3 B.U.G. | T4 B.U.G. | T5 B.U.G. | Watts |
|---|---|---|---|---|---|---|
| 1 | CAB-16L-40-27K7 | - | - | - | - | 21 |
| 2 | CAB-16L-40-27K8 | - | - | - | - | 21 |
| 3 | CAB-16L-40-30K8 | - | - | - | - | 21 |
| 4 | CAB-16L-40-30K7 | - | - | - | - | 21 |
| 5 | CAB-16L-40-35K8 | - | - | - | - | 21 |
| 6 | CAB-16L-40-40K8 | - | - | - | - | 21 |
| 7 | CAB-16L-40-40K7 | - | - | - | - | 21 |
| 8 | CAB-16L-40-50K8 | - | - | - | - | 21 |
| 9 | CAB-16L-40-50K7 | - | - | - | - | 21 |
| 10 | CAB-16L-53-30K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B2-U3-G1 | 28 |
| 11 | CAB-16L-53-40K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B2-U3-G1 | 28 |
| 12 | CAB-16L-53-50K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B2-U3-G1 | 28 |
| 13 | CAB-16L-7-30K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B3-U3-G1 | 36 |
| 14 | CAB-16L-7-40K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B3-U3-G1 | 36 |
| 15 | CAB-16L-7-50K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G1 | B3-U3-G1 | 36 |
| 16 | CAB-16L-1-30K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G2 | B3-U3-G1 | 56 |
| 17 | CAB-16L-1-40K7 | B1-U3-G1 | B2-U3-G2 | B1-U0-G2 | B3-U3-G1 | 56 |
| 18 | CAB-16L-1-50K7 | B1-U3-G1 | B1-U3-G1 | B1-U0-G2 | B3-U3-G1 | 56 |
| Order | Milliamps | 16L |
|---|---|---|
| 1 | 400 mA (40) | 21w |
| 2 | 530 mA (53) | 28w |
| 3 | 700 mA (7) | 36w |
| 4 | 1050 mA (1) | 56w |
| Order | Model | T2 Lumens | T2 Lm/W | T3 Lumens | T3 Lm/W | T4 Lumens | T4 Lm/W | T5 Lumens | T5 Lm/W | Watts |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | CAB-16L-40-27K7 | 2,007 | 96 | 1,990 | 95 | 1,937 | 92 | 2,078 | 99 | 21 |
| 2 | CAB-16L-40-27K8 | 1,880 | 90 | 1,863 | 89 | 1,814 | 86 | 1,945 | 93 | 21 |
| 3 | CAB-16L-40-30K8 | 2,015 | 96 | 1,998 | 95 | 1,945 | 93 | 2,086 | 99 | 21 |
| 4 | CAB-16L-40-30K7 | 2,170 | 103 | 2,152 | 102 | 2,094 | 100 | 2,246 | 107 | 21 |
| 5 | CAB-16L-40-35K8 | 2,015 | 96 | 1,998 | 95 | 1,945 | 93 | 2,086 | 99 | 21 |
| 6 | CAB-16L-40-40K8 | 2,170 | 103 | 2,152 | 102 | 2,094 | 100 | 2,246 | 107 | 21 |
| 7 | CAB-16L-40-40K7 | 2,345 | 112 | 2,325 | 111 | 2,263 | 108 | 2,427 | 116 | 21 |
| 8 | CAB-16L-40-50K8 | 2,170 | 103 | 2,152 | 102 | 2,094 | 100 | 2,246 | 107 | 21 |
| 9 | CAB-16L-40-50K7 | 2,345 | 112 | 2,325 | 111 | 2,263 | 108 | 2,427 | 116 | 21 |
| 10 | CAB-16L-53-30K7 | 2,968 | 106 | 2,940 | 105 | 2,856 | 102 | 3,052 | 109 | 28 |
| 11 | CAB-16L-53-40K7 | 3,080 | 110 | 3,052 | 109 | 2,968 | 106 | 3,192 | 114 | 28 |
| 12 | CAB-16L-53-50K7 | 3,192 | 114 | 3,164 | 113 | 3,080 | 110 | 3,304 | 118 | 28 |
| 13 | CAB-16L-7-30K7 | 3,816 | 106 | 3,780 | 105 | 3,672 | 102 | 3,924 | 109 | 36 |
| 14 | CAB-16L-7-40K7 | 3,960 | 110 | 3,924 | 109 | 3,816 | 106 | 4,104 | 114 | 36 |
| 15 | CAB-16L-7-50K7 | 4,104 | 114 | 4,068 | 113 | 3,960 | 110 | 4,248 | 118 | 36 |
| 16 | CAB-16L-1-30K7 | 5,936 | 106 | 5,880 | 105 | 5,712 | 102 | 6,104 | 109 | 56 |
| 17 | CAB-16L-1-40K7 | 6,160 | 110 | 6,104 | 109 | 5,936 | 106 | 6,384 | 114 | 56 |
| 18 | CAB-16L-1-50K7 | 6,384 | 114 | 6,328 | 113 | 6,160 | 110 | 6,608 | 118 | 56 |
![]()
![]()
– Low depreciation rate
– Light Distributions are Type 2, 3, 4 and 5- Dark Sky compliant—full cut-off design for Commercial applications.
– Silicone Micro Optics which produce 96% clarity and are rated up to 200° C (50% higher than acrylic)
– High performance LEDs and Driver combinations for consistency and high reliability
– Philips Advance 0-10V Dimming Driver technology warranted 5 years—best voltage variance resistance in our industry.
– Conforms to the strictest Made in America standards. Designed, tooled, fabricated and assembled in the USA
NLS Lighting, LLC is an American outdoor LED lighting manufacturer located in Southern California. Our specification grade architectural and commercial products feature high efficacy and NLS' Dark Sky compliant Impact Rated Optics with Glare Control Option and Visual Comfort Full Cutoff patented Star PowerTM optical technology that exceed IES required light levels utilizing the least amount of energy. Our qualified team of outdoor lighting experts stands behind Intelligent Light + Performance®.
